Product Details
Place of Origin: China
Brand Name: ANS
Certification: TUV，CE
Model Number: ANSAG-T2-22kW
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: USD
Packaging Details: standards export package
Delivery Time: 20-30days
Payment Terms: L/C, D/A, T/T, D/P, Western Union
Supply Ability: 1000pcs one day
Product Name: |
Type 2 Ev Charging Cables |
Amps: |
32A |
Voltage: |
480V |
Connector Standard: |
Type 2 Tethered Cables |
Length: |
5M |
Materials: |
HUNTSMAN, SABIC, DUPONT |
Plug Standard: |
IEC 62196 |
Grounding: |
Standard Grounding |
Warranty: |
24 Months |
Phase: |
3phase |
Product Name: |
Type 2 Ev Charging Cables |
Amps: |
32A |
Voltage: |
480V |
Connector Standard: |
Type 2 Tethered Cables |
Length: |
5M |
Materials: |
HUNTSMAN, SABIC, DUPONT |
Plug Standard: |
IEC 62196 |
Grounding: |
Standard Grounding |
Warranty: |
24 Months |
Phase: |
3phase |
-Standard charging plug, it can be identified by EV correctly and charge effectively.
-Rugged design. Its structural strength is sufficient enough to support the rolling of an electric car.
-Unique Arc Extinguishing technique makes sure that there won't have any electric sparks when plugging in and plugging out.
-Safe & Reliable. The cable is made of flame-retardant TPU material, which can withstand the direct fire combustion within a safe time.
-Durable. The advanced Crimping Technology ensures a working life of over 3000 times safe plugging in.
|
ProductModel: |
ANSAG-T2-16A |
|
|
Product Type |
Type 2 ev charging cable |
|
|
Stardard: |
IEC 62196-2 |
|
|
Rated Voltage: |
AC 480V |
|
|
Rated Current: |
32A |
|
|
Withstanding voltage: |
2500V |
|
|
Working temperature: |
-30℃ to +65℃ |
|
|
StorageTemperature: |
-40℃ to +70℃ |
|
|
Terminal temperature rise: |
<50K |
|
|
Contact impedance: |
0.5mMax |
|
|
Protection level: |
IP55 |
|
|
Certifications: |
TUV CE |
|
|
Warranty: |
2 years |
|
|
Plug Colour: |
Black, Red, Orange, Yellow, Green, Blue or Customization |
|
|
Mechanical life: |
No-load plug in/pull out>10000 times |
|
|
Insertion and Extration Force: |
45N<F<100N |
|
|
Impato fex ternal force: |
Can afford 1m drop and 2T vehicle run over pressure |
|
|
Part name |
Material |
Supplier |
|
Cable |
PUR (TPU) |
HUNTSMAN: A85P4380 |
|
Shell of plug |
PC+PBT |
SABIC:V3900WX |
|
Head of plug |
PA66+GF25 |
DUPONT: FR50 |
Applied Materials
Our business scope includes charging pile equipment, wind power generation equipment, photovoltaic power generation equipment
and other products, providing targeted products and solutions for government public power, transportation service charging, and private
supporting power supply facilities.
All the products are produced in strict accordance with CQC standards, and obtained CCC, TUV, UL and other certifications.
We adhere to the development concept of high efficiency, energy saving and environmental protection. With independent innovation and customer service as the foundation; market-oriented, quality of survival. We firmly believe that we will surely set sail and create brilliance!
Certification:TUV,CE,RoHS, REACH, ISO 14001:2015,IATF16949
