Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box

Brand Name:	ANS
Model Number:	ANS-AFWB-11kW
MOQ:	1
Price:	USD
Packaging Details:	180mm180mm70mm
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Brand:

Product Name:

11kW AC EV Charging Station

Application:

AC Home Charging

Control:

APP, OCPP, Bluetooth

Rated Current::

Connection:

WIFI, Ethernet

Protection Level::

Warranty:

2 Years

Certifications::

CE, RoHs

Operating Temperature::

-30℃-+50℃

Supply Ability:

1000PCS/month

Highlight:

16A Solar EV Charging Station

11kW Solar EV Charging Station

480V Solar EV Charging Station

Product Description

7kW- 22kW Home Charging Wallbox Station with Dynamic Load Balance Box

Product Description

Power Specification
AC Power Input Rating	SAE Standard	IEC Standard
	AC Level 2	1-Phase	3-Phase
	240V	220V ± 15%	380V ± 15%
AC Power Output Rating	3.5kW/16A	3.5kW/16A	11kW/16A
	7kW/32A	7kW/32A	22kW/32A
	10kW/40A	N/A	N/A
Rated Frequency	50/60Hz	50/60Hz	50/60Hz
Connector Type	SAE J1772 (Type 1)	IEC 62196-2 (Type 2)
User Interface & Control
Charging Control	Plug and Play, RFID Card or App
Display Screen	3.0-inch LCD Screen
Voice Prompt (Optional)	Voice guide of the charging process in English
Indicators	LCD display-Power/Connect/Charging/Fault
External Communication	Wi-Fi, bluetooth, Solar system, DLB box
OCPP Protocol (Optional)	1.6 or 2.0.1
Environmental
Storage Temperature	-40 to 75℃ (-40 to 167℉) ambient
Operating Temperature	-30 to 55℃ (-22 to 131℉) ambient
Operating Humidity	Up to 95% non-condensing
Altitude	≤2000m
Protection
Protection Ratings	IP 65	RCD	Type B
Over Voltage Protection	Yes	Under Voltage Protection	Yes
Over Load Protection	Yes	Short Circuit Protection	Yes
Earth Leakage Protection	Yes	Ground Protection	Yes
Over-temp Protection	Yes	Surge Protection	Yes
Wallbox Mechanical
Dimension (H x W x D, mm)	180mm180mm70mm
Weight	1-phase＜6kg; 3-phase＜8kg
Charging Cable Length	5m or Customize Length

Product Detail

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 0

EM3-Box

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 1

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 2

EM3 can be used for EVE series AC EV charging stations, or other

chargers compatible with EM3 Box. When the EV charging station

works simultaneously with other household appliances, EM3 Box

can maintain the dynamic balance of the total household current,

ensuring household safety and avoiding overloading of the grid.

If PV CT is installed, EM3 Box can achieve multiple modes of use for

both the grid and PV.

PV Mode : Almost no electricity is obtained from the grid.

Min+PV Mode : Minimal grid power and solar energy to meet the

minimum 6A charging requirement for EV.

Fast Mode : Charge the EV as fast as possible based on the load of

the grid and the current setting of the charging station.

LCD display

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 3

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 4

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 5

Features

✔ OCPP, WIFI, Bluetooth, dynamic load balance

✔ Each wallbox EV charger comes with its APP

✔ Total 10 Lauguages, including French, German, Russian, etc., the language also supports customization

✔ Type A+DC6mA makes charging more safer

✔ compatible with solar system

✔ Each EV charging station is with emergency stop botton

✔ Standby power consumption<5W save much energy

✔ 180mm*180mm*70mm small design makes anywhere is possible



FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery or others let's discuss

Q3. What is your terms of delivery?
A: FOB, CFR, CIF, DDU, EXW

Q4. How about your delivery time?
A: Generally, it will take 3 to 25 days after receiving your advance payment. The specific delivery time depends

on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample for beginning testing.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 7

Certification

Solar EV Charging Station 11kW 16A 480V 3 Phase with DLB EM3 Box 8
