Product Details
Place of Origin: China
Brand Name: ANS
Certification: TUV, CE
Model Number: ANS-30kW
Payment & Shipping Terms
Minimum Order Quantity: 1pc
Price: USD
Packaging Details: standard export package
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, Western Union, T/T, MoneyGram
Supply Ability: 500pcs a week
Product Name: |
Charger Power Module |
Power: |
30kW |
Communication: |
CAN Bus |
Frequency: |
45-65Hz |
Voltage Range: |
150Vdc -1000V Dc |
Cooling: |
Fan Cooling |
Power Factor: |
0.99 |
Product Name: |
Charger Power Module |
Power: |
30kW |
Communication: |
CAN Bus |
Frequency: |
45-65Hz |
Voltage Range: |
150Vdc -1000V Dc |
Cooling: |
Fan Cooling |
Power Factor: |
0.99 |
EV Charging Module for EV Charging Station 30kW 1000V Charger Power Module
30kW1000V Charger Power Module
Product Introduction
The moduel designed for EV DC chargers. It has high efficiency,low fan noise,high power density and high reliability advantage.3 phase 4wire AC input, DC output voltage range is from 150 to 100VDC with 30kW output power, EMC/EMl satisfyTUy CE certicificationwith class Blevel, and safety satisfy both TUV UL and CE certicification.
Main feature:
Application:
DC Charger for EVwith modular design,easily maintenance,cost efficiency, high power density and high quality
Ambient Temperature | -40℃ ~+75℃,derating from 55℃ |
Storage Temperature | -40℃~ + 70C |
Humidity | 95%RH,non-condensing |
Cocling | Fan cooling |
Altitude | 2000m |
Communication | CAN bus,Max 48power modules parallel |
lndication Light | Green LED: normal operation Yelikow LED:alarm Red LED: failure |
Address Indication | Automatic address identification,Panel dial switch for group setting |
Noise Setting | Power mode with max 75 dB , Deroise mode with max 65 dB ,Quier mode with |
Super Standby | |
Outerside 12v or 5sv Do control |
